This machine is installed on the foam conveyor line,to cut the continuously foam to some length, in order to transport, storage and processing. This machine adopts digital control, and two cutting way(Saw-toothed and blade) for cutting, users can choose the cutting way depend on their own needs, and solve the risk of machine halt because of blade breaking. The machine is simple to operate and cut precisely.
Model |
ZXCD-2400A |
Cutting foam height |
1300mm |
Cutting foam width |
2400mm |
Blade frame moving speed |
21m/min |
Conveyer belt speed |
0~8m/min |
power |
9Kw |
machine external size |
L3700xw1300xH2300mm |
